Mainboard Supermicro MBD-X11DPG-QT-B

Mô tả chi tiết

Hãng sản xuất

Supermicro

Chủng loại

MBD-X11DPG-QT-B

CPU hỗ trợ

2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors, , Dual Socket LGA-3647 (Socket P) supported, CPU TDP support Up to 205W TDP, 3 UPI up to 10.4 GT/s

Chipset

Intel® C621

Bộ nhớ trong

Up to 4TB 3DS ECC RDIMM, DDR4-2933MHz; Up to 4TB 3DS ECC LRDIMM, DDR4-2933MHz Or 2TB DCPMM, DDR4-2666MHz, in 16 DIMM slots; Up to 2TB Intel® Optane™ DC Persistent Memory in memory mode (Cascade Lake only).

VGA onboard

Aspeed AST2500 BMC

Âm thanh

7.1 HD Audio Header

Khe mở rộng

6 PCI-E 3.0 x16,

1 PCI-E 3.0 x4 (in x8 slot)

Chuẩn lưu trữ

M.2 Interface: PCI-E 3.0 x4

10 SATA3 (6Gbps) port

Intel® C621 controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10

Cổng giao tiếp

4 USB 2.0 ports (2 rear + 2 headers)

5 USB 3.0 ports (2 rear + 2 headers + 1 Type A)

1 VGA D-Sub Connector port

2 COM Ports (1 rear, 1 header)

1 TPM Header

LAN

Dual LAN with Intel® X550 10GBase-T Ethernet Controller

Kích thước

Proprietary  (38.4cm x 33.53cm)

Phụ kiện đi kèm
